Conductores de cobre electrolítico recocido, sólido, cableado ó flexible.
Aislamiento de PVC en doble capa hasta 10 AWG y 6 mm2. Aislamiento
en una capa desde 8 AWG y 10 mm².
Características
Buena resistencia dieléctrica, resistencia a la humedad, productos
químicos, grasas, aceite y al calor hasta la temperatura de servicio.
Retardante a la llama.
Marca
INDECO S.A. TW-80 450/750 V
Calibres
1.5 mm² - 300 mm²
16 AWG - 350MCM
Embalaje
De 1.5 a 10 mm²: En rollos estándar de 100 metros.
De 10 a 300 mm²: En carretes de madera.
Colores
De 1.5 a 10 mm²: Amarillo, azul, blanco, negro, rojo y verde.
Mayores de 16 mm²: Solo en color negro.
Normas de Fabricación
NTP 370.252
Tensión de servicio
450/750 V
Temperatura de operación
80ºC
TABLA DE DATOS TECNICOS TW - 80 (mm²) |
CALIBRE CONDUCTOR |
N° HILOS |
DIAMETRO HILO |
DIAMETRO CONDUCTOR |
ESPESOR AISLAMIENTO |
DIAMETRO EXTERIOR |
PESO |
AMPERAJE (*) |
AIRE |
DUCTO |
mm² |
mm |
mm |
mm |
mm |
Kg/Km |
A |
A |
ALAMBRES |
1.5 |
1 |
1.36 |
1.36 |
0.7 |
2.8 |
20 |
18 |
14 |
2.5 |
1 |
1.74 |
1.74 |
0.8 |
3.4 |
31 |
30 |
24 |
4 |
1 |
2.21 |
2.21 |
0.8 |
3.9 |
45 |
35 |
31 |
6 |
1 |
2.70 |
2.70 |
0.8 |
4.3 |
64 |
50 |
39 |
10 |
1 |
3.51 |
3.51 |
1 |
5.6 |
107 |
74 |
51 |
CABLES |
1.5 |
7 |
0.52 |
1.50 |
0.7 |
2.9 |
21 |
18 |
14 |
2.5 |
7 |
0.66 |
1.92 |
0.8 |
3.5 |
32 |
30 |
24 |
4 |
7 |
0.84 |
2.44 |
0.8 |
4.0 |
48 |
35 |
31 |
6 |
7 |
1.02 |
2.98 |
0.8 |
4.6 |
68 |
50 |
39 |
10 |
7 |
1.33 |
3.99 |
1 |
6.0 |
114 |
74 |
51 |
16 |
7 |
1.69 |
4.67 |
1 |
6.7 |
172 |
99 |
68 |
25 |
7 |
2.13 |
5.88 |
1.2 |
8.3 |
269 |
132 |
88 |
35 |
7 |
2.51 |
6.92 |
1.2 |
9.3 |
364 |
165 |
110 |
50 |
19 |
1.77 |
8.15 |
1.4 |
11.0 |
490 |
204 |
138 |
70 |
19 |
2.13 |
9.78 |
1.4 |
12.6 |
690 |
253 |
165 |
95 |
19 |
2.51 |
11.55 |
1.6 |
14.8 |
959 |
303 |
198 |
120 |
37 |
2.02 |
13 |
1.6 |
16.2 |
1192 |
352 |
231 |
150 |
37 |
2.24 |
14.41 |
1.8 |
18.0 |
1476 |
413 |
264 |
185 |
37 |
2.51 |
16.16 |
2 |
20.2 |
1837 |
473 |
303 |
240 |
37 |
2.87 |
18.51 |
2.2 |
22.9 |
2392 |
528 |
352 |
300 |
37 |
3.22 |
20.73 |
2.4 |
25.5 |
3002 |
63 |
391 |
TABLA DE DATOS TECNICOS TW - 80 (AWG / MCM) |
CALIBRE CONDUCTOR |
SECCION
NOMINAL |
N° HILOS |
DIAMETRO HILO |
DIAMETRO CONDUCTOR |
ESPESOR AISLAMIENTO |
DIAMETRO EXTERIOR |
PESO |
AMPERAJE (*) |
AIRE |
DUCTO |
(AWG / MCM) |
mm² |
mm |
mm |
mm |
mm |
Kg/Km |
A |
A |
ALAMBRES |
16 |
1.3 |
1 |
1.36 |
1.36 |
0.7 |
2.8 |
20 |
18 |
14 |
14 |
2.1 |
1 |
1.74 |
1.74 |
0.8 |
3.4 |
31 |
30 |
24 |
12 |
3.3 |
1 |
2.21 |
2.21 |
0.8 |
3.9 |
45 |
35 |
31 |
10 |
5.3 |
1 |
2.70 |
2.70 |
0.8 |
4.3 |
64 |
50 |
39 |
8 |
8.4 |
1 |
3.51 |
3.51 |
1 |
5.6 |
107 |
74 |
51 |
CABLES |
14 |
2.1 |
7 |
0.60 |
1.75 |
0.8 |
3.4 |
21 |
18 |
14 |
12 |
3.3 |
7 |
0.76 |
2.20 |
0.8 |
3.8 |
32 |
30 |
24 |
10 |
5.3 |
7 |
0.96 |
2.78 |
0.8 |
4.4 |
48 |
35 |
31 |
8 |
8.4 |
7 |
1.20 |
3.61 |
1 |
5.6 |
68 |
50 |
39 |
6 |
13.3 |
7 |
1.53 |
4.60 |
1 |
6.6 |
114 |
74 |
51 |
4 |
21.1 |
7 |
1.93 |
5.80 |
1.2 |
8.2 |
172 |
99 |
68 |
2 |
33.6 |
7 |
2.44 |
7.31 |
1.2 |
9.7 |
269 |
132 |
88 |
1/0 |
53.4 |
7 |
1.87 |
8.58 |
1.4 |
11.4 |
364 |
165 |
110 |
2/0 |
67.4 |
7 |
2.10 |
9.60 |
1.4 |
12.4 |
490 |
204 |
138 |
3/0 |
85.1 |
19 |
2.35 |
10.82 |
1.6 |
14.1 |
690 |
253 |
165 |
4/0 |
107.2 |
19 |
2.65 |
12.15 |
1.6 |
15.4 |
959 |
303 |
198 |
350 |
177.5 |
37 |
2.44 |
15.69 |
2 |
19.7 |
1192 |
352 |
231 |
|
